15KW Electric Pool Heater - 110V/220V Above Ground & Inground Swimming Pool Water Heater with Digital Thermostat | Perfect for Backyard Pools, Hot Tubs, and Spa Heating | Fast & Energy Efficient Heating Solution
Delivery & Return:Free shipping on all orders over $50
Estimated Delivery:7-15 days international
People:23 people viewing this product right now!
Easy Returns:Enjoy hassle-free returns within 30 days!
Payment:Secure checkout
SKU:87631524
Product Description
Note: 1.This machine can be used with Single-phase 220V or dual-phase 110V2.please confrim the wire referring to the power of the unit,here are the current of different type of machine9KW/220V = 41A,about 41A9KW/220V = 41A,about 41A11KW/220V =50A, about 50A15KW/220V =68A,about 68A18KW/220V =82A,about 82ASpecifications: Liner material: stainless steelVoltage: 110/220V (Transformer required) Power: 15KW Phase: single phase Connection size: 40 mm (1.57 ") Machine size: 49 x 10 x 38 cm / L x W x H. Suitable for: hot tub & swimming pool equipmentDescription:Intelligent temperature control, stable performance, safe and reliableAutomatic constant temperature, can be set according to the required water temperature.The maximum set temperature is approx. 55 ° C.Safe and reliable, mechanical pressure switch.When the pressure is below the set value, the power supply is automatically switched off.Do not heat sea water or salt water.The thermostat must work with a water pump with an appropriate capacity.(If the pump and thermostat do not match, the flow rate is too low, the heating pipe is dry and can easily be damaged.)5.5KW-15KW heaters must operate with a pump with a water flow of at least 177 ft³ / hour (5m³/hour).The 15KW thermostat is suitable for a pool of ≤ 353 ft³ / 10m³It is recommended to use the thermostat with a circulating water pump:Manual reset temperature switchTemperature limit switchFuse protectionPower protection switchSmart self-diagnosis functionThe control system continuesly monitors the operating status of all parts of the heater, rea
Product Features
【Temperature Adjustment】The thermostat is designed to maintain a preset temperature level at a standard bath water temperature range of 68°F-131°F (20°C-55°C). However, if the bath is cold during startup, the thermostat will increase the temperature by 6 to 8°C based on the initial water temperature, room temperature and bath size.
【Above Ground Pool Heaters】Swimming pool heater is suitable for heating small hot springs, swimming pools and other constant temperature systems. Capacity no more than 2641 Gallon swimming pool equipment; must operate with a pump with a water flow of at least 177 ft³ / hour (5m³/hour).
【Instructions】According to the power of the thermostat equipped with the appropriate power cord, the thermostat comes with the 3-pin power cord connected to the terminal near the terminal box, the power supply for the 110/220V - 240V / 50 ~ 60Hz, brown fire line that L terminal, blue The dyed line is the N terminal, and the yellow and green lines are connected to the ground line.
【Safety】If an error occurs, the pool heater will stop immediately and a message will appear on the control panel so that the user or technician can determine where the error is. The safety of the customer is a top priority. It is recommended to use the thermostat with a circulating water pump
【Installation】With detailed installation instructions and two interfaces. It can be installed indoors or outdoors, fixed on a smooth and flat surface. This high-quality electric pool water heater is commonly used indoors and outdoors, especially for swimming pools, SPA pools, and bathtubs.
